Description

GigaMAX low bed semi-trailer

The GigaMAX low bed semi-trailer is characterised by one or two pendle-axle dolly that is permanently attached to the gooseneck.

This allows for an extremely compact overall towing length with a long loading area at the same time. The integrated pendle-axles increase the payload at the front of the vehicle.

  • Low dead weight
  • Compact design
  • High agility
  • Ideal manoeuvrability

    • Gooseneck

    Central beam neck

    The absence of coupling points between the gooseneck and the front bogie results in a considerable weight reduction for the GigaMAX.

    Nevertheless, the gooseneck bogie is detachable from the lowbed, allowing easy coupling and loading of any vehicle from the front.

  • For more payload possibilities
  • Optimum load distribution
  • With 1 or 2 pendle-axles
  • Provides ideal overall length

    • STANDARD: W25 with 17.5” pendle-axles, W30 with 19.5” pendle-axles, Spare wheels with winch, Hydraulic screw coupling

    OPTION: Hydraulic multi-coupling, Power Pack, Mechanical fine-tuning of the fifth wheel load, Toolbox on the gooseneck

    Low bed versions at a glance

    Low beds come in many versions and payload categories for the GigaMAX. The complete range of products at Faymonville allows for a variety of uses.

  • Excavator deck
  • Outer beams with fixed floor
  • Widening outer beams
  • Outer beams with removable floor
  • Vesseldeck with hydraulic widening
  • Flatbed deck

    • The bogies at a glance

    Bogie technologies

    The low-bed semi trailer GigaMAX is equipped with hydraulic suspension and hydraulic pendle-axles.

    The excavator trough

    Each bogie type includes as standard a deep and large excavator trough. When moving different kind of excavators or demolition machines, the boom is integrated in the trough of the GigaMAX.

    A useful technology to reduce the total transport height considerably. This allows to master height restrictions when bridges or power lines need to be passed.

    Areas of activity

    Applications

    This type of vehicle makes it possible to comply with legal height restrictions despite high loads. Lowbed trailers can make the difference to clear underpasses, bridges and power lines, so even the most difficult missions reach their destination.

    The strengths of the GigaMAX low bed certainly lie in its length-optimised and weight-optimised construction. These properties enable not only adherence to legal boundary conditions, but also increase manoeuvrability and efficiency in loading and transport.

    The GigaMAX low bed semi-trailer is suitable for the transport of:

  • Heavy construction machines for excavation and road construction, recycling, road planing machines, crushing equipment, screening equipment
  • Wind power plants such as tower segments, generators, rotor or turbine blades, hybrid towers
  • Steel and concrete elements
  • Industrial parts such as transformers, crane-loaded goods or for ring transport
  • Cranes, crane weights, crane components
  • Conveying and crushing systems for the demolition and recycling industry
  • Track-guided vehicles: trams, locomotives, wagons
  • Boats and yachts
  • Precast concrete parts
  • Bulky goods and heavy loads
    • Show All

    Specifications

    ConditionNew
